How to measure for custom size, made to measure shaker doors and cabinet doors.

Replacing your kitchen doors is one of the most cost-effective ways to transform the appearance of your kitchen without the expense and disruption of a full renovation. Whether you're ordering custom size shaker doors, replacement cabinet doors, or a complete set of made-to-measure kitchen doors, accurate measurements are essential to ensure a perfect fit.

In this guide, we'll explain exactly how to measure your existing kitchen doors and drawer fronts so you can confidently order bespoke shaker doors manufactured to your exact dimensions.

Many kitchens use non-standard cabinet sizes, particularly older kitchens or bespoke installations. Made-to-measure shaker doors allow you to:

- Replace existing doors without changing cabinets

- Refresh outdated kitchens at a fraction of the cost of a new kitchen

- Achieve a premium, bespoke appearance

- Match existing cabinetry dimensions exactly

- Avoid expensive alterations to existing units

At RS Bespoke, all shaker doors are manufactured to order, ensuring every door fits perfectly.

Before you begin, gather the following:

- Tape measure

- Pencil and notepad

- Smartphone or camera

- Masking tape (optional)

- Spirit level (optional)

For best results, measure in millimetres (mm).

The simplest and most accurate method is to measure your existing doors.

Remove one door from the cabinet and measure:

Door Width

Measure from the left-hand edge to the right-hand edge of the door.

Example:

Width = 597mm

Door Height

Measure from the top edge to the bottom edge.

Example:

Height = 715mm

Your door size would therefore be:

597mm x 715mm

When ordering replacement shaker doors, simply enter these exact dimensions.

Drawer fronts are measured in exactly the same way.

Measure:

- Overall width

- Overall height

Example:

597mm x 140mm

If replacing multiple drawer fronts, measure every drawer individually, as sizes often vary.

If your doors are missing or damaged, you can measure the cabinet opening instead.

Measure:

- Opening width

- Opening height

Then add the appropriate overlay.

Most kitchens use a door overlay of approximately 17-20mm per side, but this can vary significantly depending on cabinet design.

If you're unsure, contact us with photographs of your cabinets and we'll help determine the correct door size.

If you'd like your new shaker doors supplied with hinge holes pre-drilled, you'll need to provide:

Number of Hinges

Most doors use:

- 2 hinges for smaller doors

- 3 hinges for medium doors

- 4 hinges for tall doors

Hinge Hole Positions

Measure from the top edge of the door to the centre of the hinge cup.

Then measure from the bottom edge to the centre of the lower hinge cup.

Example:

- Top hinge centre = 100mm

- Bottom hinge centre = 100mm

For doors with three or more hinges, record all hinge positions.

Although we manufacture fully bespoke shaker doors, some common kitchen door sizes include:

- 297mm x 715mm

- 397mm x 715mm

- 497mm x 715mm

- 597mm x 715mm

- 597mm x 140mm (drawer front)

- 597mm x 283mm (drawer front)

Remember that many kitchens contain non-standard sizes, so always measure rather than assume.

The measuring process is exactly the same for painted shaker doors.

Whether you choose:

- Unfinished MDF shaker doors

- Primed shaker doors

- Professionally painted shaker doors

The dimensions required remain unchanged.

Measuring Cabinet Openings Instead of Doors

Whenever possible, measure the actual door rather than the cabinet.

Assuming All Doors Are Identical

Check every door individually. Manufacturing tolerances and previous replacements can lead to slight differences.

Using Centimetres

Always measure in millimetres for maximum accuracy.

Forgetting Drawer Fronts

Many customers focus on doors and forget to measure drawer fronts until later.

Absolutely.

Whether you need:

- One replacement kitchen door

- A replacement integrated appliance door

- A single custom size shaker door

We manufacture doors individually to your exact requirements.

Our made-to-measure shaker doors are manufactured in-house using precision CNC machinery and moisture-resistant MDF for exceptional accuracy and durability.

Benefits include:

- Custom sizes available

- Fast UK delivery

- Trade and retail orders welcome

- Premium moisture-resistant materials

- Optional painted finishes

- Precision CNC manufacturing

- Single doors or complete kitchen sets

If you're unsure about any measurements, simply send us photographs of your kitchen doors or cabinets and we'll be happy to help.

Our team can guide you through the process to ensure your replacement shaker doors fit perfectly first time.

---
